Aluminum polyester tape (single side)
Product Description:
The raw material of aluminum polyester tape is soft aluminum foil and a polyester film, compound with intaglio coating, slitting and rolling when aluminum foil polyester was done, the structure is a layer of aluminum foil and a layer of polyester film. (AL/PET)
Application: Apply to magnetic field with non-electromagnetic or precipitation static, such as communication cables, data cable, and shielding of signal cable, can match with coating, it can be used in assemble shielding and grounding when aluminum foil polyester was cut.
Aluminum foil polyester include: Aluminum polyester tape (single side), Aluminum polyester tape (double side), Free edge aluminum polyester tape, Heat sealed aluminum polyester tape, Aluminum polyester foil tape, Composite aluminum-plastic tape.
Main specifications:
Specification | Composition | Elongation （%） | Tensile strength （Mpa） | Basis weight （g/m²） | Peel strength (N/cm) | |
AL | PET | |||||
22±10%μm | 7μm | 12μm | 35↑ | 60↑ | 39±10% | 6.3↑ |
25±10%μm | 7μm | 15μm | 35↑ | 60↑ | 43±10% | 6.3↑ |
30±10%μm | 7μm | 20μm | 35↑ | 60↑ | 51±10% | 6.3↑ |
25±10%μm | 9μm | 12μm | 35↑ | 60↑ | 45±10% | 6.3↑ |
27±10%μm | 9μm | 15μm | 35↑ | 60↑ | 49±10% | 6.3↑ |
35±10%μm | 9μm | 23μm | 35↑ | 60↑ | 61±10% | 6.3↑ |
27±10%μm | 12μm | 12μm | 20↑ | 60↑ | 53±10% | 6.3↑ |
30±10%μm | 15μm | 12μm | 20↑ | 60↑ | 62±10% | 6.3↑ |
43±10%μm | 20μm | 20μm | 20↑ | 60↑ | 86±10% | 6.3↑ |
53±10%μm | 25μm | 25μm | 20↑ | 60↑ | 107±10% | 6.3↑ |
70±10%μm | 40μm | 25μm | 15↑ | 60↑ | 147±10% | 6.3↑ |
65±10%μm | 50μm | 12μm | 10↑ | 60↑ | 156±10% | 6.3↑ |
73±10%μm | 50μm | 20μm | 15↑ | 60↑ | 167±10% | 6.3↑ |
In addition to the above specifications, other special requirements can design according to customers | ||||||
